wheel loader with Cummins or shangchai or weichai engine or ZF Transmission case similar to XCMG ZL50GN

Name: wheel loader with Cummins or shangchai or weichai engine or ZF Transmission case similar to XCMG ZL50GN
Brand: WEA/WORLD
Price: 36000 USD

Brand Name : WEA/WORLD

Model Number : W156

Place of Origin : CHINA

MOQ : one unit

Price : $36000-$43000

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 5000 units per year

Delivery Time : 20-30 working days

Packaging Details : by container

Rated load (Kg) : 5000

Operating weight(kg) : 16500

Max breakout force : ≥175KN

maximum tractive force : 145KN

maximum grade ability : 30℃

maximum dump height : 3142mm

maximum dump reach : 1250mm

overall dimension (L×W×H) : 8085×2965×3450mm

minimum turning radius : 6732mm

Engine Model : Shangchai C6121 engine

No. of cylinder-bore/stroke : 6－121×152mm

rated power : 162kw--2200r/min

maximum torque : 843N.m

min fuel-consume ratio : ≤215g/kw.h

gearbox mode : Power shift planetary structure

gear shift : 2 forward shift and1 reverse shift

maximum speed : 38km/h

fuel tank capacity : 292L

function of leveling automatically : yes

type specification : 23.5-25

Contact Now

wheel loader with Cummins or shangchai or weichai engine or ZF Transmission case similar to XCMG ZL50GN

Specificaiton:

Performance	1	rated load	5000kg
	2	overall weight	16500kg
	3	rated bucket capacity	3.0m³
	4	maximum tractive force	145KN
	5	maximum breakout force	≥175KN
	6	maximum grade ability	30℃
	7	maximum dump height	3142mm
	8	maximum dump reach	1250mm
	9	overall dimension (L×W×H)	8085×2965×3450mm
	10	minimum turning radius	6732mm
Engine	11	model	Shangchai C6121 engine
	12	type	lnline water cooling dry cylinder injection
	13	No. of cylinder-bore/stroke	6－121×152mm
	14	rated power	162kw--2200r/min
	15	maximum torque	843N.m
	16	min fuel-consume ratio	≤215g/kw.h
Transmission system	17	torque converter	Single stage two phase four components
	18	gearbox mode	Power shift planetary structure
	19	gear shift	2 forward shift 1 reverse shift
	20	maximum speed	38km/h
Drive axles	21	main reducing spiral	bevel gear grade 1reduction
	22	decelerating mode	planetary reduction,grade 1
	23	wheel base (mm)	3250mm
	24	wheel tread(mm)	2250mm
	25	minimum ground clearance	450mm
Hydraulic system	26	system working pressure	18MPa
	27	boom lifting time	5.1s
	28	total time	9.3s
	29	fuel tank capacity	292L
	30	function of leveling automatically	yes
Brake system	31	service brake	air over hydraulic disc brake on 4 wheels
Brake system	32	parking brake	Break air brake
Tyre	33	ype specification	23.5-25
	34	Front wheel air pressure	0.4Mpa
	35	Rear wheel pressure	0.35Mpa

1.A name-brand Engine, high power, low oil-consumption, low noise and reliable performance.

2.Double turbine hydraulic torque converter,planet power shifting transmission and higher transmission efficiency.

3.Reinforced axles by optimization of European technology has stronger bearing capacity, more stronger driving power and higher reliability
4.Rear frame with box structure, hinged panels with low stress and high strength steel——sturdy and durable；
5.Hydraulic parts and components such as cylinder, pump, valve all adapt domestic and international famous brands——stable and reliable.

wheel loader with Cummins or shangchai or weichai engine or ZF Transmission case similar to XCMG ZL50GN

FAQ

1. Are you manufacturer?

Yes, we are a manufacturer located in jiangsu porvince which is in the manufacturing center of construction machinery.

2. What kind terms of payment can be accepted?

Normally we can work on T/T or L/C term.

3. What about the delivery time?

7-30 days after receiving the deposit.

4. what about the warranty time?

12 months after shipment or 2000 working hours

5. what is the delivery method?

one unit use one pc 40HC container.
